JPL SprayTex

By JPL Innovations Pvt. Ltd.

Sprayable Elastomeric Texture • Four Architectural Finishes • Class A Fire Rated

JPL Terrashield Texture Spray is a sprayable decorative version of Terrashield Fine, applied with a multi-nozzle gun to create finishes like orange-peel, splatter, knock-down, and stucco. Overcoated with JPL emulsions, it delivers a durable, premium façade finish.

Sprayable Elastomeric Texture
No on-site cement-mix tinting — ready to spray straight from the pail.
Four Architectural Finishes
Multi-nozzle gun delivers orange-peel, splatter, knock-down, and stucco from the same product.
Class A Fire Rated
Carries Terrashield Fine chemistry — Class A fire, anti-fungal, and water-resistant performance.
Polymer-Bound Granules
Does not chalk, debond, or detach over time — long-lasting finish integrity.
Buy Now
Call to place your order

Product Overview

Terrashield Texture Spray is a sprayable decorative version of Terrashield Fine, applied with a multi-nozzle gun to create finishes like orange-peel, splatter, knock-down, and stucco. Overcoated with JPL emulsions, it delivers a durable, premium façade finish.

Compatible with the full JPL paint range for colour and sheen specification. Bridges hairline cracks and absorbs thermal and structural movement.

Technical Advantages

Designer textured façade performance in a single elastomeric system — faster, stronger, and more durable than traditional trowel-applied stucco.

1

No Cement-Mix Tinting

Sprayable elastomeric texture eliminates on-site cement-mix tinting — consistent colour and finish every time.

2

Crack-Bridging Elastomeric

Bridges hairline cracks and absorbs thermal and structural movement without debonding or delaminating.

3

Faster Site Application

Faster site rate versus trowel-applied stucco with lower waste and rebound — saving time and cost.

4

BOQ-Ready Reference Shades

Matches the BOQ-ready 8T-2699 / 8D-2703 reference shades from Krisumi for seamless project specification.

Application Procedure — JPL SprayTex

📄 Download JPL SprayTex TDS

Step 1 — Base Build-Up

  • Apply 1–2 coats of Terrashield Fine (2 × 1 mm) and allow to dry per TF TDS.

Step 2 — Texture Coat

  • Spray 1 coat of tinted Terrashield Texture Spray through the multi-nozzle gun in the chosen finish (orange-peel, splatter, knock-down, stucco).

Step 3 — Topcoat

  • After ≥ 96 hours, apply 1 coat of JPL emulsion (Exto / Weathertouch / Spade / Into / Premium) for colour, plus optional Clear Emulsion for shine and sheen.

Coverage

Max. Thickness Area in Sq.Ft / 20 Kg
1.5–2 mm450

Note: Coverage values may vary based on nozzle size, finish type, and surface texture. Conduct site trials before full application.

NABL Test Results

As per Terrashield Fine Base

Test Result
Fire Retardant Surface RatingClass 1 or A
Compressive Strength3.2 MPA
Tensile Strength5.8 MPA
Flexural Strength1.9 MPA
Absorption (submerged 24 hrs)24.3%
Pull-off Strength1.0 MPA

Applications

←
